CQI-9 Heat Treat Audit: A Drifting Thermocouple Can Fail the Whole Furnace

A CQI-9 assessment looks beyond final part quality. Auditors review whether heat treat processes are controlled as documented, including process tables, job audits, system accuracy tests, temperature uniformity surveys, and calibration records. For manufacturers running heat treat across multiple plants, those records also need to remain consistent and traceable to specific equipment and dates.

This article breaks down what a CQI-9 heat treat system assessment reviews, which records auditors scrutinize most, and how CQI-9 fits into the broader family of AIAG special process assessments.

What A CQI-9 Heat Treat Assessment Actually Reviews

A CQI-9 heat treat audit does not stop at final part inspection. Auditors walk through process tables for the specific method in use, whether that is carburizing, nitriding, or induction hardening, and check that documented parameters match what the equipment is actually running. Job audits follow individual parts through the process to confirm that time, temperature, and atmosphere controls hold up in practice, not just on paper. The assessment itself was developed by the Automotive Industry Action Group with input from OEMs, Tier 1 suppliers, and heat treat and calibration companies, specifically to give the industry one common way to audit these processes rather than a different checklist at every plant.

Instrumentation gets equal scrutiny. Auditors expect to see system accuracy tests and temperature uniformity surveys performed on schedule, with records that trace back to specific furnaces and dates. For automotive manufacturers running the same heat treat process across multiple sites, maintaining consistent production and quality records becomes part of the broader challenge of meeting audit and traceability requirements. FlowFuse connects to furnace controllers and PLCs over protocols such as OPC UA and Modbus. It logs each setpoint and actual reading against the furnace ID and a timestamp, so a job audit can compare what ran with what the process table says. It can do this across automotive plants that run different equipment.

This scope is narrower than it might first appear. A CQI-11 plating assessment centers on coating thickness and adhesion, while CQI-9 stays focused on thermal process control from furnace load to final output.

Layered process audits can help keep these checks consistent on the shop floor.

Instrumentation, Calibration, And Documentation Auditors Scrutinize

A CQI-9 assessment puts as much weight on paperwork as it does on the furnace itself. Auditors need proof that every instrument reading is accurate, every calibration cycle was completed on time, and every corrective action left a clear, traceable record across the facility. Three areas of documentation tend to draw the closest attention.

System Accuracy And Uniformity Testing

Auditors verify that system accuracy tests and temperature uniformity surveys were performed at the required frequency and by qualified personnel. Missing or late testing is one of the most common findings in a heat treat audit. Manufacturers that treat this as a scheduled operational task, not a once-a-year scramble, consistently pass this section with fewer corrective actions noted. A FlowFuse flow can work out the next SAT and TUS due date for each furnace and alert the quality team before a test lapses, instead of relying on someone to check a spreadsheet.

Instrument Calibration Records

Every thermocouple, controller, and recording device tied to the heat treat process needs a documented calibration history: the recorded comparison of an instrument against a reference of known accuracy to identify measurement drift, as ASQ defines calibration. For that comparison to serve as audit evidence, it should have a documented traceability chain to recognized measurement standards, such as NIST for U.S. manufacturers. Auditors trace these records back to specific equipment and dates, making strong instrument calibration practices essential to maintaining audit-ready records.

Traceability Across Sites

For manufacturers running the same heat treat process across multiple plants, auditors expect consistent documentation practices everywhere, not just at headquarters. A calibration management dashboard built in FlowFuse can bring calibration due dates, overdue instruments, and compliance status into one view. Because the same application can be deployed to every plant, each site tracks calibration the same way.

How CQI-9 Fits Into The Broader CQI Special Process Family

CQI-9 is one of several AIAG special process assessments, with each assessment focused on a different manufacturing process. Understanding the differences helps manufacturers determine which assessments apply when multiple special processes are performed across the same facility or supply chain. Here is how the related standards break down.

Welding System Assessments

CQI-15 is the Welding System Assessment, which applies to organizations performing applicable ferrous and non-ferrous metallic welding. Like CQI-9, it provides a common approach to assessing a specific special process within automotive production and service part organizations.

Soldering System Assessments

CQI-17 applies the same self-assessment structure to soldering operations, with process tables built around flux control, solder temperature, and joint inspection instead of furnace parameters. A facility running both heat treat and soldering lines needs to satisfy both standards independently, since neither audit covers the other's scope, and treating them as one review would leave gaps in both process records.

Molding System Assessments

CQI-23 covers molding system assessments. A facility that performs both heat treat and molding needs to address the requirements of each applicable assessment separately. For manufacturers managing quality across multiple sites, defect and quality monitoring can help teams track quality trends and recurring defects across production operations.

Final Thoughts

Passing a heat treat audit comes down to proving that what happens on the furnace matches what is written in the procedure, every time, at every site. That means accurate instrumentation records, calibration history that traces back to specific equipment, and job audits that hold up under scrutiny. None of that is achievable with manual tracking spread across spreadsheets and site-specific habits, especially for manufacturers running heat treat processes at scale across a brownfield environment.

Audit readiness is easier when the process data an assessment needs is captured during normal production, not reconstructed from spreadsheets before an audit. With FlowFuse, teams can build a production monitoring application once and deploy it to every heat treat site. It collects furnace readings, alarms, and calibration status in the same structure at each plant, so the evidence is already there when the auditor asks for it.
